CHEMICAL TANK

We manufacture customized chemical tanks that meet international standards, using in-house produced HDPE (PERC / PERT) and PPH sheets, along with state-of-the-art fusion equipment and precise CNC machining. These tanks are designed for maximum safety, long-term corrosion-free use, excellent chemical resistance, and reliable performance even at high temperatures.

Advantages

Chemical tanks are designed and produced according to DVS2005 / DVS 2005 & DVC 2007-4, and all butt-welding conducted according to DVS 2007-1.

01

Excellent chemical resistance and corrosion resistance of HDPE/PP-H

No worries about corrosion and rust
02

High-strength HDPE material containing carbon black

No problem with sunlight exposure with strong UV Protection
03

Use of PP-H raw materials

Can be used up to 90℃
04

High-strength HDPE/PP-H material

Maintains a sturdy basic structure
05

Round/square/multi-angle manufacturing according to user convenience

Possible to freely design according to site conditions

PE 100 (HDPE) material meets the MRS 10 Mpa, and carbon black dispersion is uniform as a compound raw material. It has excellent processability, excellent resistance to chemicals and abrasion. In addition, it can be used outdoors Thanks to its strong UV resistance. Although PERC (Polyethylene Resistance to Crack) is the same raw material as PE100, it is highly recommended in fields where physical properties deteriorate due to internal and external scratches caused by low-speed cracking resistance.

PP-H (Polypropylene Homopolyer) is a raw material with enhanced strong chemical resistance / abrasive resistance and high temperature pressure resistance. It can be used up to 90°C and can be used for a variety of purposes, including acids, alkalis, organic solvents, and pure water. It is used in chemical tanks that require high temperature and strong chemical resistance, working flow of secondary battery material production, steel cold rolling lines, and plating tanks.

FRP (fiber Reinforced Plastics) is a semi-permanent material that is stronger than iron and lighter than aluminum by impregnating unsaturated polyester resin with glass fibers as reinforcement.

FR-LSZH (Frame Retardant – Low Smoke Zero Halogen) contains flame retardants on the outer surface of the product, making it a UL 94 VO grade flame retardant that keeps your storage safe from fire.

D.W (Double-Walled) Chemical Tank
features a dual-wall structure ensuring a high level of safety. The inner tank stores the chemicals, while the outer tank encases the inner tank, providing secondary containment and preventing leaks.

Customized TANK

The following OPTIONS are available for customized tank production: If you select OPTION, you can request a quote along with the model of the tank you want.

Company name

Name

Tel

E-mail

Material

Structure

Handrail & Loader: Yes No

Type of connecting pipe

Agitator: Yes No

Operating temperature: °C

Capacity: tons

Number of Nozzle: nozzles

Using Chemical

Customized TANK Check →

Select your desired option and
find images of your customized Tank

Contact us about customized Tanks and get a detailed consultation!
